• Accurate and mobile lead board
  • Highly efficient and stable automatic-feed system of planing with the workpiece pressed
  • Double-action back type planer protecting sheet
  • The inverse motion stopper absolutely guarantees the security of operation of planing with the workpiece pressed

    ZICAR Carpentry Machine

    Brand

    ZICAR

    Model

    MQ442A
    Product Specification
    Max. planing width 250 mm
    Max. planing capacity 3 mm
    Max. open cutting depth 10 mm
    Max. sawing thickness 85 mm
    Press planing thickness range 6 – 120 mm
    Min. press-planing length 150 mm
    Max. mortise 16 x 16 mm
    Speed of cutter spindle 3,500 r/min
    Speed of the feeding of press-planing 6.5 m/min
    Motor 220V, 1.1kW
    Overall dimension 1036 x 1250 x 930 mm
    Net Weight 185 kg
